Responsible for helping maintain drilling mud circulation throughout your drill string, quality mud pumps are essential parts of your equipment suite. Our reliable brand models such as the F-1000, FD-1600, 12-P-160, and 14-P-220 operate with high performance, easy maintenance, and durability to meet the toughest demands. These field-proven models rate in the 500- to 2,200-hp range. Our extensive product line of mud pumps also includes the National P-Series and Continental Emsco FD-Series and F-Series.
Specifications
| Maximum input | 1,600 hp (1193 kW) |
| Rated pump speed | 120 spm |
| Maximum fluid cylinder liner bore | 7¼ in. (184.2 mm) |
| Hydrostatic test pressure of fluid cylinders | 10,000 psi (703 kg/cm2) |
| Gear ratio | 3.439 |
| Suction connection ASA-150 lb. R.J. flange, inches | 10 in. |
| Discharge connection, cross w/ API-10,000 psi. R.J. flange | 6 in. |
| Valve pot, API number | MOD. 7 |
