Husky 15120 Air-Operated Diaphragm Pumps
1.5 inch Positive Displacement Double Diaphragm Pump
The Husky 15120 has a 1.5 inch (38.1 mm) connection and is available in polypropylene and PVDF.

The Husky 15120 air-operated diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover.
The one-piece center section eliminates leaks and reduces maintenance on Husky pumps when compared to other diaphragm pumps.

Benefits of the Husky 15120 double diaphragm pumps
Overall improved efficiency (up to 40% more efficient)
Highest fluid flow rate in its class
Up to 5 times longer diaphragm life compared to other air operated diaphragm pumps
Expanded material offering to handle endless applications

Overview
Maximum fluid flow- 122 gpm (462 l/min)
Maximum Fluid Discharge- 25 psi (8.6 bar, 0.86 MPa)
Maximum size pumpable solids- ¼ in (6.3 mm)
Fluid displacement per cycle- 0.66 gallons (2.5 liter)

Features:
1-1/2 in (38.1 mm) ANSI center and end-porting options available
High flow - 120 gpm (454 lpm) in a compact, portable size
Fluid pressure to 125 psi (8.6 bar, 0.86 MPa)
Lube-free operation
Available in polypropylene and PVDF

Material:
Antifreeze
Windshield Washer Fluid
Diesel Exhaust Fluid (DEF)
Detergents
Cutting Oil
Water
Water - Wastewater Treatment
Water - Wastewater Transfer
Water - Freshwater Treatment

Applications:
Chemical Transfer
Diesel Exhaust Fluid (DEF) Transfer and Dispense
Bulk Supply System
Medium-Viscosity Material Transfer
Low-Viscosity Material Transfer

Industries:

Professional Cleaning
Hazardous Cleaning
Automotive Electronics
Consumer Electronics
Chemical Manufacturing
Electronics Manufacturing
Mining - Wastewater Transfer
Chemical Dosing Pumps for Refineries
Fleets
Water - Wastewater Treatment
Water - Wastewater Transfer
Water - Freshwater TreatmentInk Transfer
