MMPL5900 Two guns road marking machine is professional choice for athletic floor and pavement working.
Electric pressure control and swivel front wheels provide excellent line quality.
Name: MMPL5900 Road Marking Machine
Max flow(L/Min):5L/min
Power type: HONDA gasoline engine
Max working pressure (Mpa):22.7MPa
Max nozzle size (in):1 gun with 0.035â€/2 guns with 0.023â€
Dynamic power (W):4125W
Motor speed: 3600
Advantages:
1.High quality pump
High quality pump is ideal for low to high viscosity traffic paints spraying.
2.Smart pressure control
Digital pressure display,easy control and operate.
3.Adjustable gun bracket
Versatile gun bracket can be adjusted according to your working demands.
4.Handle bars control
Both handle bars control are designed for mor confort and better control without stopping production.
5.Swivel front wheels
Swivel front wheel makes striping up to the curb easier. Stripe arcs and curves with ease.
MODEL |
MMPL5900 |
MAXIMUM FLOW |
|
MAXIMUM FLOW |
5L / MIN |
MAXIMUM WORKING PRESSURE |
227BAR / 3300PSI |
NOZZLE SIZE |
1 GUN WITH O.035" / 2 GUNS WITH 0.025" |
POWER SOURCE |
GASOLINE HONDA ENGINE |
DYNAMIC POWER |
4125 W / 5.5 HP |
MOTOR SPEED |
3600 |
GROSS WEIGHT |
146 KGS |
PACKAGE SIZE |
123 X 84 X 82CM |
MATERIAL APPLICATIONS |
SOLVENT LINE MARKING PAINTING & WATER BASED LINE MARKING PAINTING |
