Viscon Fluid Heaters  High performance fluid heaters
Provides excellent temperature conditioning for high solids coatings and high viscosity materials

Graco's Viscon heaters maintain optimal temperatures to provide consistent control of fluid viscosity. With a wide temperature operating range, Viscon heaters are excellent for any coating, sealant, adhesive or lubricant you need to pump.

Viscon HF High Flow Fluid Heaters
- Designed for high flow rates, with more power for faster material heating

Viscon HF Fluid Heaters for Explosive Atmospheres
- Developed to handle the highest viscosity coatings such as 100% solids epoxies coatings and epoxy fireproofing materials

Viscon HP High Output Fluid Heaters
- Offers high pressure (7250 psi/500 bar) for use with most pumps

Features:

Viscon HF High Flow Fluid Heater:
Spiral passages provide three times the flow rate of standard Viscon heaters
Efficient and powerful for faster material heating - gets the job done faster
Available in manual thermostat or externally controlled versions
Excellent for high solids coatings and protective coatings materials
Easy to clean and maintain
7250 psi (500 bar, 50 MPA)
Temperature operating range: 84 to 219°F (29 to 104°C)

Viscon HF Fluid Heaters for Explosive Atmospheres:
The patent-pending design has a triple-path spiral core that can be easily disassembled for cleaning.
Increased flow capacity: The Viscon HF has over three (3) times more flow capacity compared to the standard Viscon HP heaters.
Increased heat capacity: The Viscon HF heaters have 35% more wattage; 5400 watts compared to 4000W for the standard Viscon HP heaters.
Available in manual thermostat or externally controlled versions.
Cleanable and replaceable fluid core – repair instead of replace.
7250 psi (500 bar, 50 MPA) pressure rating – handles the highest pressure rating of Graco protective coating sprayers.
Temperature operating range: 84 to 219°F (29 to 104°C)
Same mounting configuration as standard Viscon HP heaters – Easy to retrofit onto existing equipment.

Viscon HP High Output Fluid Heater:
Higher pressure for use with most pumps
Excellent for high solids coatings, adhesives or resins
7/16 in (11 mm) diameter fluid passages
Stainless steel design
Available in standard or explosive atmosphere versions
7250 psi (500 bar, 50 MPa)
Temperature operating range: 84 to 219°F (29 to 104°C)
